Stihl SE 122 - Page 19

SE 122
English
17
Definitions
1 Suction Hose
Directs collected dirt and/or liquid
into the container.
2 Handle Tube
For holding and guiding the
respective tool.
3Switch
To switch the machine in position
ON and OFF.
4Latch
Holds motorhead onto the
container.
5 Vacuum Intake Port
Connection between container and
suction hose.
6 Caster with Brake
Locks the vacuum cleaner in place.
7 Container
Captures and stores collected dirt
and/or liquid.
8 Holder for Tools and Accessories
Accommodates nozzles and
accessories on the vacuum cleaner.
9 Filter Cleaning Button
Press to clear the filter of deposited
dust.
10 Handle
For holding and carrying the
vacuum cleaner.
11 Suction Hose Holder
For storing the suction hose.
12 Extension Tube
Directs collected dirt and liquids
from the tool to the suction hose.
13 Floor Tool
For cleaning smooth surfaces and
carpets.
14 Extension Tube Holder
For storing the extension tube.
15 Crevice Tool
For cleaning places that are hard to
reach.
16 All-purpose Tool
Tool for numerous potential uses.
Motor
Performance data
Dimensions
Weight
Specifications
Power Supply: 120 V, 60 Hz,
8,3 A
Electrical Rating: 1000 W
Circuit Breaker: 15 A
Insulation: Double
Insulation E
Max. intake capacity,
air:
113 cf/min
(3200 l/min)
Max. vacuum: 230 mbar /
91 in H
2
O
Length approx.: 19 in (485 mm)
Width approx.: 15 in (385 mm)
Height approx.: 24 in (600 mm)
Container capacity: 8 gal (30 l)
Length of suction
hose: 10 ft (3 m)
Inside diameter: 1.4 in (36 mm)
ca. 22 lbs (10 kg)
