INSTALLATION
NOTICE:
The decorative arms in the next two steps are not
required for fan operation. You may skip these two
steps if you do not wish to install the decorative
arms.
Install the decorative arms using the hex wrench
provided. Attach one side of each arm to the center
arm support using the long socket head cap screws
(M4 x 10 mm) and screw covers as shown.
Finish the assembly by screwing the finial screw on each
arm into the threaded holes in the top lens cover.
Restore power to the room and wall switch. Turn on the
wall switch, then refer to the remote control operating
instructions in the next section to test the fan’s operation.
DECORATIVE ARM
SCREW
COVERS
CAP
SCREWS
FINIAL
SCREW
DECORATIVE ARM
