CS58 Cap Stapler
LOADING'THE'TOOL'
USE 5/8
”
STINGER STAPLEPAC
®
CAP STAPLES ONLY
• Disconnect air.
• Open the magazine cover by pushing the green cover release
tab and lifting.
• Place cap reel in basket. Make sure the front end of the cap
coil is placed over the cap guide area of the basket. Insert
lead cap into the feed chute.
• Slide caps along the feed chute with fingers until they engage
the cap feeder. Pull the cap feeder back and release to
advance caps until the first cap is under the nose of the tool.
• Close the magazine cover.
• Depress the latch on the staple follower and pull back. Insert
two staple strips. Slide staple follower in and secure.
• Plug into air source. Tool is ready to use.
5
