© 2019 Stinger • www.stingerelectronics.com
Amplier Owner’s Manual
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >110dB
High and Low Pass Crossovers: 12dB per Octave
Low Pass Crossover Range: 40Hz to 400Hz
High Pass Crossover Range: 40Hz to 400Hz
Input Range: 200 millivolts to 12 volts
Typical Efciency: 80%
Damping Factor: Greater than 200
Recommended Fuse Size: 60 amp
Power/Ground Wire Size: 8 Gauge
Dimensions: 206mm L x 120mm W x 41mm H
8.1” L x 4.73” W x 1.6” H
Specications
Specications
RMS Power (14.4Vdc ≤1% THD):
125 x 4 @ 4 ohm Stereo
175 x 4 @ 2 ohm Stereo
125 x 2 @ 4 ohm Stereo +
350 x 1 @ 4 ohm Bridged*
(Rear Channels only)
Lowest Recommended Load:
4 ohm Bridged* or 2 ohm Stereo
*Only Rear Channels controlled by
Remote Level Knob.
SP X700x4
SPX700X4
4 Channel Power Amplier
8.8in/223.4mm
4.73in/120mm
1.6in
41mm
8.1in/206mm
