• Carefully turn the cooktop back over and then gently lower it into the
aperture hole that you have cut out.
• There are four mounting slots on the base of the cooktop where you can
affix the four brackets (Fig. 3).
• Place a bracket each in the slots on the underside of the cooktop, as
illustrated in Fig. 4.
• Using the screws provided, affix the bracket to the cooktop and then
tighten the screws securely (Fig. 5). This is very important.
• The other end of the bracket should be located underneath the benchtop
to secure the hob in position.
Installation (Cont.)
Fig. 3
Mounting slots
Fig. 5
Fig. 4
NOTE: Fig. 4 and Fig. 5 illustrate how to affix the brackets to the cooktop.
At this stage of the installation process the cooktop should be sitting
securely in the benchtop cut-out and the sealing tape should be fitted
around the edge.
