Introduction
1.6 Operation Processing
Only 3 steps to operate our TFT-LCD Module:
⚫ Build a new project by STONE GUI Design Software.
⚫ Connect with customer’s MCU through RS232,RS422,RS485,TTL directly, Plug & Play.
⚫ Write a simple program for MCU to control the TFT-LCD Module via Instruction Sets.
The communication protocol is built with 2 parts:
1）Initiative Instruction - JSON Code (MCU→TFT-LCD Module)
Frame header instruction code widget type widget name data Frame tail
ST< {"cmd_code":"set_value","type":"label","widget":"label2","value":5} >ET
2）Passive Instruction - HEX Code (TFT-LCD Module→MCU)
Frame header CMD LEN DATA Frame tail CRC16
53 54 3C 10 62 00 09 6C 61 62 65 6C 3F A1 47 AE 3E 45 54 6C 8B
More information, please refer to the document of Instruction Sets.
