DO NOT CONTINUE YOUR COOLER INSTALLATION UNLESS YOU ARE CERTAIN THAT THE
PANELS ARE LOCKING COMPLETELY LEVEL.
6. When installing the Door panel, DO NOT REMOVE THE DOOR FROM DOOR FRAME. Cut the
“shipping metal band” at the bottom of the door panel with a pair of metal snips. Follow
the same recommendations as when installing the wall panels. Door frame panel must be
LEVEL and PLUMB. Ensure it is flush at the top with all adjacent panels.
TIPS FOR PROPER DOOR INSTALLATION ON COOLER WITH NO FLOOR
See drawing on next page
Level and plumb door frame and frame legs are level to each other. Shim under door
frame to achieve level and plumb.
Frame legs are to be in plane with each other. Check with 4’ straight edge across door
face at bottom of doorway.
Frame legs are to be parallel and not spread out. Opening width at bottom of
doorway to match width at top of doorway.
After all walls are installed, verify function of door, door locks and emergency release
when door is locked.
Adjust door closer if needed.
Verify that door sweep lightly drags on floor when opening/closing door.
IMPORTANT!
Door and frames have been checked for proper fit and operation at the factory. An
unleveled floor my cause doors to not hang or close properly. This can occur initially at
the time of installation or at a later date due to heavy traffic. It may be necessary to shim
under the walk-in floor or door frames at one side or the other to adjust a misaligned
frame.
Loosening and relocking frame cam locks may also permit some adjustment. Make sure
legs are parallel to each other and to adjacent wall panels. The door may not seal properly
if the frame is twisted or out of plumb. See problems figure on next page.
Step 7 & 8 on next page.
