STOREX AIVX-391NMT - QUICK START GUIDE - © STOREX 2009 PAGE 7/42
DETAIL OF THE PRODUCT
Front
1 – On/off light 4 – Infrared remote control receiver
2 – Disk activity light
3 – Display, 1 line (VDF)) Side - SD, SDHC & MMC card reader
Rear panel
12V input 7 Network connector (RJ45
2 Fan 8 – Ports USB 2.0 Host (x2)
Power switch 9 HDMI video output
4 RCA video output 10 S-video output
5 YUV video output 11 Optical audio outpu
6 Coaxial audio output 12 – USB 2.0 Port Device (PC)
Cartridge
1
2
2
3
1
12 11
10
7
8
9
4
5
6
3
4
