Item 60338
Page 16
For Generator technical questions, please call 1-800-444-3353.
For Engine technical questions, please call 1-800-520-0882.
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description Qty.
1 Left Crankcase 1
2 Right Crankcase 2
3 Bearing (6004) 2
4 Hole Circlip (#42) 1
5 Oil Seal (20 x 30 x 7) 2
6 Pin (10 x 7 x 14) 2
7 Stud (AM6 x 50) 2
8 Flange Nut (M6) 4
9 Flange Bolt (M6 x 45) 4
10 Stud (AM6 x 100) 2
11 Oil Seal (6 x 12 x 7) 1
12 Governor Shaft 1
13 Washer (6 x 10) 2
14 Governor Fork 1
15 Cross Round Head Bolt (M3 x 8) 2
16 Spring Washer (#3) 2
17 Governor Arm 1
18 Collar Bushing 1
19 Weight Comp 1
20 Flange Bolt (M6 x 16) 4
21 Crankshaft Assy. 1
22 Circlip 2
23 Piston Pin 1
24 Roller Bearing (14 x 10 x 14) 1
25 Piston 1
26 Second Piston Ring 1
27 First Piston Ring 1
28 Cylinder Gasket 1
29 Cylinder 1
30 Cylinder Cap Gasket 1
31 Cylinder Cap 1
32 Flange Bolt (M6 x 105) 2
33 Nut (M6 x 18) 2
34 Cylinder Cap Cover 1
35 Flange Bolt (M6 x 12) 10
36 Ignition Coil Assy. 1
37 Clamp 1
38 Spring Washer (#6) 7
39 Cross Round Head Bolt (M6 x 16) 2
40 Flywheel 1
41 Flange Nut (M10 x 1.25) 1
Part Description Qty.
42 Recoil Starter Assy. 1
43 Intake Valve Gasket 1
44 Intake Valve Assy. 1
45 Flange Bolt (M6 x 20) 4
46 Stud (AM6 x 60) 2
47 Intake Gasket 1
48 Carburetor 1
49 Carburetor Gasket (B) 1
50 Carburetor Gasket (A) 1
51 Supporting Plate 1
52 Compression Spring 1
53 Cross Round Head Bolt (M6 x 40) 1
54 Rod Link 1
55 Tension Spring 1
56 Governor Spring 1
57 Control Panel 1
58 Capacitor 1
59 Self Tapping Screw (ST4.2 x 13) 1
60 Alternator Stator 1
61 Alternator Rotor 1
62 Flange Bolt (M8 x 156) 1
63 Rear Cover 1
64 Flange Bolt (M6 x 80) 3
65 Washer (#6) 3
66 Flange Bolt (M6 x 10) 2
67 Muffler 1
68 Muffler Gasket 1
69 Flange Bolt (M6 x 16) 2
70 CDI Winding 1
71 Spark Plug 1
72 Absorber 4
73 Fuel Tank 1
74 Strainer 1
75 Fuel Cup 1
76 Fuel Tank Cap 1
77 Handle 1
78 Cross Round Head Bolt (M6 x 30) 1
79 Washer (#6) 2
80 Fuel Switch 1
81 Rubber 1
82 Choke Lever 1
To Next Page
