CD80/CD80AE Processor Retrofit Kit
Installation Guide
PREFACE
1. About This Guide
The document provides installation and operation instructions for the following products:
• 76698-0004 CD80/CD80AE Processor Retrofit Kit (C21 Processor, 120V Markets)
• 76698-0005 CD80/CD80AE Processor Retrofit Kit (EC21 Processor, 230V Markets)
WARNING! CD80/CD80AE Processor Retrofit Kits are not interchangeable, and must be installed in the
appropriate voltage CD80AE Dimming Rack.
Please read all instructions before installing or using this product. Retain this guide for future reference.
2. Additional Manuals
Refer to the originally-supplied CD80AE manual for dimming rack operation and care.
OVERVIEW
1. About CD80/CD80AE Processor Retrofit Kits
CD80/CD80AE Processor Retrofit Kits provide C21 (for 120V markets) or EC21 (for 230V markets) dimming
processors to existing CD80 and CD80AE Dimming Racks. These processors represent premium performance and
high value for all levels of users. Designed to interface directly with Strand Lighting’s ShowNet Ethernet, the
processors include an Ethernet port. An available Ethernet switch option may be added to any processor to simplify
network wiring for multiple rack installations.
Two DMX512 inputs are standard with the second input available for use as an RS485 input to support existing
Outlook or SWC systems or our new Vision.net architectural controls.
All systems are easy to set up and configure over a network using a standard web browser to access rack status and
configuration options.
2. Installation Overview
The following items are required to successfully install an CD80/CD80AE Processor Retrofit Kit:
• Review this document completely before starting the installation.
• Unpack and inspect equipment. Compare the equipment and parts you received with the informat
ion contained in
"In
cluded Items" on page 4. If these do not match, contact Strand Lighting Customer Service at: 1-800-4STRAN
D
(U
.S.) or 1-214-647-7880.
• Become familiar with the existing processor and wiring before performing the installation instructions contained in
this guide.
