FEATURES
Strand Vision.Net is a fully integrated lighting management system designed to meet the most demanding
lighting environments. Scalable from a single room to large multi-building campuses, our decentralized control
approach delivers unparalleled flexibility and maximum reliability. Designed to integrate with all Strand dimming
systems, low voltage switching cabinets, Vari-Lite and Strand fixtures, Vision.Net can control any lighting load
with intuitive precision.
Advanced programming of Vision.Net components can be done using Designer for Vision.Net. Certification is
required to access Designer for Vision.net software. Register for certification courses on our website.
COMPONENTS
The document provides installation and operation instructions for the following products:
• Vision.Net Control Stations on page 7
– VISION.NET PORTABLE STATIONS
– VISION.NET KEYSWITCH STATIONS
– VISION.NET WALL STATIONS
• VISION.NET DIN Rail Enclosures on page 11
– VISION.NET DIN RAIL ENCLOSURE - LARGE
– VISION.NET DIN RAIL ENCLOSURE - SMALL
• VISION.NET DIN Rail Rack Trays on page 13
– VISION.NET DIN RAIL RACKMOUNT TRAY - HORIZONTAL
– VISION.NET DIN RAIL RACKMOUNT TRAY - VERTICAL
• VISION.NET GATEWAY on page 14
– VISION.NET GATEWAY MODULE - DMX/RDM INTERFACE (4 port)
– VISION.NET GATEWAY MODULE - RS485 INTERFACE (1 port)
• VISION.NET MODULES on page 15
– DATA SPLITTER (4 WAY)
– DIGITAL I/O (4 PORT)
– DIGITAL INPUT (8 PORT)
– DMX512 (1 UNIVERSE)
– RS232 AND USB (Also available in a single-gang US back-box format)
• VISION.NET SENSORS on page 16
• VISION.NET
TOUCHSCREENS on page 18
– VISION.NET PORTABLE TOUCHSCREEN (10.1”)
– VISION.NET TOUCHSCREEN PROCESSOR
– VISION.NET TOUCHSCREEN (10.1”)
Read all instructions before installing or using this product. Retain this manual for future reference. Additional
product information and descriptions may be found on the product specification sheet.
