Key Features
1...... Power Button 7...... SD Card Reader 13.... IO Shield Slot
2...... Power LED 8...... IR Receiver Window 14.... eSata Slots (Optional)
3...... ODD Eject Button 9...... Heat Sink 15.... PCI Slot
4...... ODD Loading Slot 10.... Heatsink Connector 16.... USB/SD Card PCB
5...... Top Panel 11.... CPU Cooler Heatpipe 17.... HDD/ODD Cage
6...... USB Ports 12.... DC Power Jack Hole 18.... Power Button PCB
2 3 5
1 6
Specification
Chassis Material Aluminum
Available Colours Silver / Black - Brushed Finish
Motherboard Compatibility Mini ITX
HDD Drive Support 1 x 3.5" + 1 x 2.5"
ODD Drive Support Slot loading drive, left side eject button
Cooling Method Passive - Heat Pipe (65W Max TDH Recommended)
Front Ports 2 x USB, 1 x SD Card Reader
Dimensions 240 × 250 × 100mm (L×W×H)
Power Supply Support Optional PicoPSU DC power
IR Solution Optional MCE Compatible IR Receiver & Remote
Net Weight 2.6KG
OVERVIEW - P3
7
4
8
9
12
13
14
11 16 17 18
10
15
