SURVIVOR LED-REPAIR INSTRUCTIONS
IV. Parts List
ITEM QTY. PART # DESCRIPTION
1) 1 90547 Face Cap Assembly-Old Style (Note A)
1 90557 Face Cap Assembly-New Style (Note B)
2) 1 905046 Face Cap O-Ring
3) 1 905027 Battery Door Assembly
4A) 1 90542 Alkaline Battery Carrier Assembly
4B) 1 90130 Battery Pack Assembly-Zone 2
5) 1 905074 Screw, Insert (ATEX ONLY)
6) 1 905089 Spacer, Switch
7) 1 900042 Pin, Battery Retaining
8) 1 900310 Pin
9) 1 900307 Clip
10) 1 900309 Double Torsion Spring
11) 2 905029 6-32 x ½ PHP, SS, Self Tapping
12) 1 905009 Bracket, Clip
13) 1 905076 LED Module Assembly-Old Style (Note A)
905082 LED Module Assembly-New Style (Note B)
14) 1 670015 Valve
15) 1 N/A Body Assembly (Note C)
Note A: ITEM 1-P/N# 90547-Face Cap Assembly includes the following items:
Qty. 1 900303 Face Cap
Qty. 1 900304 Lens
Qty. 1 903059 SL-90X O-Ring Lens
Qty. 1 905034 Reflector-Old Style
Important: Must be used with P/N#905076/LED Module Assembly-Old Style
Note B: ITEM 1-P/N# 90557-Face Cap Assembly includes the following items:
Qty. 1 900303 Face Cap
Qty. 1 900304 Lens
Qty. 1 903059 SL-90X O-Ring Lens
Qty. 1 905083 Reflector –New Style
Important: Must be used with P/N#905082/LED Module Assembly-New Style
Starting with Bodies with Serial Number 216821 Survivor LED
And Serial NumberA014945 Survivor LED ATEX.
Page 12 of 14 DEC. 2011
