6 BA_560_A4_180619_en
2.4
Recommended rated speed 1600 min
-1
Technical Data
Motor power 400 W
Number of tack stitches 6, 8, 10, 12, 14
Toothed belt pulley/machine Z = 38
Toothed belt profile HDT 5M-9
Kind of stitch Single thread blindstitch spot tacking
Stitch type 101
Needle system GROZ-BECKERT 1717 VRUE
Needle size 90
Thread polyester continuous filament
Thread size 120/2
Air pressure 6 bar
Average air consumption
Cl. 560-11 290 l/h
Cl. 560-21 380 l/h
Required space (m) 0.6 x 1.06
Noise:
medium noise level at a speed of
n = 1200 min
-1
LpAm 72 dB (A)
Noise test according to DIN 45635-48-1 KL3
