18 MA_560_A4_180619_en
3.5.4
Setting the thread wiper (Fig. 10)
ATTENTION!
Switch off machine electrically!
In the lower Stop position the distance between needle plate and thread wiper
should be 0.5 mm.
The upper end is by loosening the nut (1) and turn the eccentric bolt (2) set.
Adjust the eccentric bolt so that the left needle entry of the thread puller has 1
mm from the needle lever (3).
Fig. 10
