Strobel 4 - Page 37

258.21.24
Elektrischer Anschlussplan Kl. 170, 560, ZM
Digitalanzeige
Electric connection diagram cl. 170, 560, ZM
Digital display
1346
+
9V
Batterie
battery
Kippschalter
flip switch
Drehpotentiometer
rotary potentiometer
Steck-Adapter EA 9044
socket adapter EA 9044
Widerstand
resistor
a
2
b
R1
5kΩ lin.
B
9 10
1
10 1A
VSS
VDD
- +
R2
137kΩ
ws / wh
ws / wh
gn / gn
br / bn
r
t
/
r
d
r
t
/
r
d
s
w
/
b
k
198.0466
