30 31
Component ST5 ST3 Torque
Foot pedal arm, FSA MegaExo
* *
38 – 41 Nm
Pedals
* *
40 Nm
Rear derailleur
* *
8 – 10 Nm
Battery box
* *
0.5 Nm
Drinking bottle holder
* *
3.5 Nm
Brake calliper
* *
6 – 8 Nm
Brake pad pins
* *
0.8 – 1.2 Nm
Special items
Screw – mudguard to frame bridge
* *
5.5 Nm
Screw – mudguard adapter to rear bottom bracket
* *
1 Nm
Screw – rear mudguard stays to frame
* *
4 Nm
Screw – number plate holder to mudguard
* *
2 Nm
Screw – light to number plate holder
* *
2 Nm
Screw – baggage carrier stays to frame
* *
5,5 Nm
Screw – front baggage carrier to mudguard
* *
3.5 – 4 Nm
Screw – rear baggage carrier to mudguard
* *
3.5 – 4 Nm
Screws – mudguard stays to fork
* *
1,3 Nm
Screw – upper mudguard to fork
* *
5 Nm
Screws – front light to stem (Supernova)
*
5 – 6 Nm
Screws – front light to stem (Roxim)
*
4 Nm
General torque for bolted connections
Steel screws in aluminum thread
M3 1.4 Nm
M4 2.0 Nm
M5 3.9 Nm
M6 6.7 Nm
M8 15.3 Nm
M10 31.5 Nm
Steel screws in steel thread
M4 2.2 Nm
M5 4.3 Nm
M6 7.4 Nm
M8 17.0 Nm
M10 35.0 Nm
