Screw connections
It is vital that all bolted connections on the
S-Pedelec have the correct torque in order to en-
sure that they are secure. Too much torque can
damage the screw, nut or component. Always use
a torque spanner to tighten screw joints. You are
not able to correctly tighten these bolted connec-
tions without this specialist tool!
If a component specifies a torque for its bolt-
ed connections, then this should be strictly ad-
hered to. Please read the instructions provided by
the manufacturer, which often list the correct
mounting torques.
When a screw connection was treated with
threadlocking adhesive (screw adhesive, e.g. Loc-
tite), threadlocking adhesive must be used when-
ever this connection is opened, loosened or re-
tightened.
Component ST5 ST3 Torque
Grip clamp (Ergon GS1-L) – handlebar stem unit/handlebar
* *
5 Nm
Brake lever clamp (HD944) – handlebar stem unit
*
5 – 7 Nm
Brake lever clamp (HD942) – handlebar
*
5 – 7 Nm
Gear lever clamp (Shimano Alfine Di2) – handlebar stem unit
*
5 – 7 Nm
Gear lever clamp (Microshift) – handlebar
*
3 Nm
Expander clip-on
*
7 Nm
Stem clamp – handlebar
*
6 Nm
Stem clamp – fork tube (aluminium)
* *
5 Nm
Headset top cap clamp – fork tube (handlebar stem unit)
* *
3,5 Nm
Plastic cover on stem
* *
0,5 Nm
SP gadget adapter
* *
0,5 Nm
Saddle subframe clamp
* *
13 – 15 Nm
Seat angle clamp
* *
10 – 12 Nm
Saddle clamp – frame – saddle supports
* *
10 Nm
Front axle
* *
20 Nm
Rear axle
* *
25 Nm
Brake disc (6-hole, front hubs)
* *
4 – 6 Nm
Brake disc (4-hole, rear hubs)
* *
9 – 11 Nm
Inner bearing, FSA MegaExo
* *
40 – 50 Nm
