Strongway 46219 - INTENDED USE; TECHNICAL SPECIFICATIONS

2
Thank you very much for choosing a Strongway product! For future reference, please complete the
owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to
become familiar with this product before you begin using it.
This machine is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this machine not be modified and/or used
for any application other than that for which it was designed. If you have any questions relative to a
particular application, DO NOT use the machine until you have first contacted the distributor to
determine if it can or should be performed on the product.
For technical questions please call 1-800-222-5381.
INTENDED USE
This Hydraulic Engine Crane is specially designed to raise, lower and transport engines, differentials,
transmissions, and other heavy loads with minimal effort. Tested for reliability and safety to meet
ASME PALD standards.
TECHNICAL SPECIFICATIONS
Item
Description
Lifting Capacity Position 1（P1）
0.5 Ton
Lifting Capacity Position 2（P2）
1 Ton
Lifting Capacity Position 3（P3）
1.5 Ton
Lifting Capacity Position 4（P4）
2 Ton
Max. Lifting Height Min. Jib ext（H1）
70-1/16 inch
Max. Lifting Height Min. Jib ext（H2）
82-5/8 inch
Length of Jib Position 1（L1）
35-7/16inch
Length of Jib Position 2（L2）
42-1/8 inch
Length of Jib Position 3（L3）
48-13/16 inch
Length of Jib Position 4（L4）
55-1/2 inch
Height of Frame（A）
7-5/16 inch
Length of Frame （B）
63-3/8 inch
Overall Height(C)
51-9/16 inch
Width of Frame Max(D).
38-9/16 inch
Distance Between Center of Rear Wheel(E)
29-1/2 inch
(SEE IMAGE ON NEXT PAGE FOR COMPLETE SPECIFICATION LAYOUT)
Safe Operating Temperature is between 40°F – 105°F (4°C - 41°C)
