CLEANING:
WARNING: UNPLUG FROM ELECTRICAL SUPPLY BEFORE CLEANING.
1. Use a soft, damp cloth (water only) for cleaning, then wipe with dry cloth.
2. Don’t not use cleaners that harm paints or plastics; i.e., bleach or ammonia.
3. Do not bend blades
Parts Diagram
Parts List
Part# Description Qty. Part# Description Qty.
1
SCREWS 6
12
POWER CORD 1
2
COUPLING (ATTACHED
TO OUTER TUBE)
1
13
FLANGE (ATTACHED
TO MOTOR)
1
3
OUTER TUBE 1
14
MOTOR 1
4
BASE 1
15
SHAFT 1
5
NUT (TO ATTACH BASE
TO OUTER TUBE)
6
16
REAR GUARD 1
6
SET KNOB (TO
CONNECTOR)
1
17
NUT (TO ATTACH
REAR GUARD TO
MOTOR)
4
7
INNER TUBE 1
18
BLADE 1
8
POSITION KNOB 1
19
SET SCREW 1
9
PIVOT BOLT 1
20
FRONT GUARD 1
10
WASHER 1
21
GRILL SCREW 1
11
NUT 1
