NOTE: It will help if before installation you grip one end of the #39 Tube with your
left hand and the other end with your right; then viewing either end of the Tube, twist
it clockwise this will increase its inside diameter and make it slip easily over its
respective Pipe Nipples. After installation, twist the Tube ends counter-clockwise and
they will grip the Nipples firmly. Secure both ends of Tube with Hose Clamps provided.
33. On electric start tractors, place #6 Battery Box in rear of Left #10L Footwell.
Align the holes and slot in #6C Brace on bottom of #6 Box with the 5/16" holes in #10L
Footwell and #1AL Body Wall. Insert each of two 5/16-18 x 3/4 Cap Screws into 5/16
Lock Washer and then into 5/16 WI Washer. Take these Screws and insert them into the
two holes in #6C Brace and pass through the "aligned" 5/16" holes in #1AL Body Wall.
Secure these Screws inside Body by engaging them into the two 5/16-18 threaded holes in
#11 Gusset - Tighten. (Check Drawing - make sure 7/8" hole in #11 Gusset is visible at
end of 7/8" slot in #1AL Wall.)
34. If you do not have electric starting, just assemble #11 Gusset as per above, but
eliminate reference to #6 Battery Box. On right rear top side of Body, mount second #11
Gusset using same "Cap Screw" procedure as in Step #33. NOTE: This "right side" #11
Gusset must be removed and its 7/8" hole slid onto lift handle of #BH-100 Rear Hitch or
ML-40 Lift Mechanism when these attachments are used. After being slid onto its res-
pective "lift handle", the #11 Gusset must be reinstalled on #1AR Body Wall - bolted to
the inside of Wall for #BH-100 Hitch; bolted to outside of #1AR Wall for ML-40 Lift.
35. Assembly for Electric Start and Lights:
NOTE: Before assembly, read these instructions thoroughly as improper assembly may lead
to damage of the electrical system.
A. Mount #6E Switch into 5/8" hole in left rear of #7 Cover. Mount from below Cover
and keep lock washer behind Cover and on top - secure with Nut. (See Wiring Diagram
for proper location of terminals.) Using 1/4-20 x 1/2 Cap Screws, WI Washers and Lock
nuts, install #6AA Solenoid to the lower inside rear wall of #6 Battery Box - keep dim-
pled end upward. (NOTE: Keep heads of Cap Screws inside Box with Cap Screw ends pro-
truding out of Box.)
B. Mount #6F Switch in 3/8" hole in center front of #7 Cover. Mount from below, keep
nuts one on either side of #7 Cover and try to keep threaded portion of Switch from
protruding above nut on top of Cover. (See Wiring Diagram for proper location of
terminals.)
:. Mount #6D Ammeter from top of #7 Cover into 2-1/8 hole in rear left of #7 Cover.
5ecure (behind Cover) by slipping the "yoke" assembly over two screw ends protruding
from rear of Ammeter. Screw securely one nut over each screw end. (NOTE: Check that
plastic insulators are properly installed in "Yoke" assembly and that the (above) two
nuts touch only these insulators and do not make metal to metal contact with any portion
of the "Yoke".)
. Take end of #6I Wiring Harness extending from bottom of #6 Battery Box and run
loosely along top inside of left #1AL Body Wall keeping harness behind and going past
1M Baffle to Engine Starting Motor.
. It is advisable at this time to wrap electrical tape along the complete length of
6I Wiring Harness to make it neat looking and to give it added abrasion resistance.
