40. Now begin bolting the Track Shoes onto the Drive Chain using the 1/4" Carriage
Bolts, Lock Washers, and nuts provided. NOTE: Shoes must be kept square with an
imaginary line running from the Front Wheel to Rear Wheel; always check this alignment
as you are putting on the Shoes so that the final track will run true. The Lawn Shoes
must be bolted on with the bent ends always pointing to the inside of the Track. The
Dozer Shoes must be bolted on so that the "gripping" edge of the Shoe is always to the
outside and the "rolled" edge of the Shoe is to the inside and points to the rear when
it is on the ground. (See Drawing).
41. Locate the #46 Steel Seat Pan such that its four 7/16" holes align with the four
3/8" holes in the "Channel" Bracket on the rear of #4 Cover. (NOTE: You may adjust
Seat Forward or Rearward by utilizing only two 3/8" holes in both cases mount with
3/8-16 x 1 Carriage Bolts, secure below "Channel" bracket with 3/8-16 Nuts and Lock
Washers.) On optional foam cushion models, work the cushion for the Seat over its Seat
Pan making sure the extra pieces of fabric at Cushion's corners are kept over the "sharp"
corners of steel Seat Pan. Draw up ends of Seat's drawstring and tie.
42. Locate #24L and 24R Left and Right Mud Fenders under their respective #10L and 10R
Left and Right Footwells. Line up the slots in Fenders with their mating 5/16" holes
in Footwells. Slip 5/16 WI Washer over the end of eight 5/16-18 x 3/4 Cap Screws and
insert (from below Fender) into the slots of Fenders and engage their respective 5/16"
hole in Footwells above. Secure above with 5/16 WI Washer and Locknut. (NOTE: "Rear-
most" Cap Screw in #24L Fender goes not only through the Fender slot and Footwell hole,
but also through the slot in the #6C Brace holding #6 Battery Box above - similarly
secure above with 5/16 WI Washer and 5/16-18 Locknut.)
43. Insert #47B Tube of #47 Brake Assembly into #4C Clip welded to the underside of
#4A Cover and insert #48 Pin and secure with 5/8 Snap Ring. (NOTE: #47D Strip must
be facing underside of #4A Cover). Insert 3/8-16 x 2-1/2 Carriage Bolt into 3/8" sq.
hole in underside of #47C Bar and insert into #50 Spring. Insert Carriage Bolt Assembly
into underside of forward 3/8 hole of #4A Cover and secure above with 3/8-16 Wing Nut.
44. IMPORTANT: On Models MD1200, 1612 and 1600 - attach Black Edging to the exposed
edge of #3B Screen on #3 Hood cover as follows:
A. Cut Edging into two lengths - each 13%" long.
B. Starting with the left rear "exposed edge" of 3B Screen, press the open "V" shaped
part of one end of a cut length of edging onto the "exposed edge" of the Screen. Con-
tinue to press on edging as you work your way to the right hand side of the "exposed
edge" of #3B Screen. NOTE: Be sure that the Black Edging is firmly attached to the
exposed edge of #3B Screen to prevent the edging from falling off during operation of
the Dozer.
C. Do the same to the "forward exposed edge" of #3B Screen.
Final Check of Assembly:
At this point, you must now go completely over the above assembly steps to make sure
that you have neither omitted parts, nor installed any parts incorrectly. With spark
plug on Engine completely removed from Engine and ignition, wire, you may now test your
complete Tractor drive train.
A. The first step is to check that when #1K "auxiliary clutch" Handle is pulled forward
and engaged in front of #1R Clip that it is sufficient to release tension on #33 Drive
Belt so that the #32 Engine Pulley may rotate freely within the #33 Belt thereby causing
absolutely no movement of #33 Drive Belt.
