PPrroodduucctt DDeessccrriippttiioonn aanndd IInntteennddeedd UUssee
The Stryker 1588 AIM (Advanced Imaging Modality) Video Camera with Infrared Compatibility (or
“1588 AIM Camera”) is an endoscopic camera system that is used to produce still and video
images in the surgical field during surgical endoscopic procedures. The system is sensitive in the
visible and infrared spectrum. The optical image is transferred from the surgical site to the camera
head by a variety of rigid and flexible scopes which are attached to the camera head. The system
consists of a camera control unit (CCU) and a camera head with an integral cable that connects to
the CCU.
A coupler is also available for attaching a scope to the camera head. The available models for
each part are listed below.
NNoottee -- For complete system requirements to use the camera’s Endoscopic Near-Infrared
Visualization (ENV) mode, see Stryker user manual P27006 (English) or P27009 (multilingual) for
the L10 LED Light Source with AIM Technology (0220-220-300).
CCoonnssoollee
1588-010-000 1588 AIM Camera Control Unit
CCaammeerraa HHeeaaddss
1588-210-105 1588 AIM Camera Head, C-Mount
1588-310-130 1588 Pendulum Camera Head with Integrated Coupler
1,2
1588-610-122 1588 AIM Camera Head with Integrated Coupler
1588-710-105 1588 AIM Inline Camera Head, C-Mount
CCoouupplleerr
1588-020-122 AIM Coupler, 18 mm, C-Mount
3
1
Complete instructions are available in Stryker user manual P29925 (English) or P29926
(multilingual).
2
Not compatible with ENV mode when the camera is used with the L10 LED Light Source with
AIM Technology.
3
Complete instructions are available in Stryker user manual P30104.
The 1588 AIM console is also packaged with the following connection cables:
• Remote cables, 2.5 mm to 3.5 mm (Qty: 2)
• DVI-I cable (Qty: 1)
• Hospital-grade power cord (Qty: 1)
Contact your Stryker representative for availability of other cables that may be required for
alternate configurations.
EN 6 P29924F
