Stryker SR-497hpc - Operation Guide Summary; Front Panel Control Identification

2
1
3
4
5
6
7
9
8
10
11
12
13
14
15
16
17
18
19
OPERATION GUIDE
For detailed descriptions of all function please see pages 5 & 6
1 LED Channel Display
2 Channel Selector
3 Dimmer / Color Button
4 +10Khz Switch
5 Noise Blanker & ANL
6 Roger Beep
7 AM/FM & PA (Mode)
8 Band Selector
9 RF Power Output Control
10 Monitor (Talkback)
11 AWI Flasher
12 Signal Strength Meter
13 Microphone Connector
14 Squelch Control
15 On/Off Volume Control
16 RF Gain
17 Microphone Gain
18 Echo Delay
19 Echo Volume - On/Off
