Stuart Boostamatic 4000 - Pump Connections

- 5 -
Cont ...
PUMP CONNECTIONS
Model Inlet
(Pump)
Outlet Fig. No.
4000 G 1 Female G 1 Female 1
6000 G 1 Female G 1 Female 1
K7-2 G 1 Female G 1 Female 3
L5-4S G 1¼ Female G 1 Female 2
L7-4S G 1¼ Female G 1 Female 2
PUMPS
Fig. 1
Reed Switch
Assembly
Reed Switch
Assembly
Reed Switch
Assembly
Inlet
Inlet
Inlet
Outlet
Outlet
Outlet
Fig. 2 Fig. 3
