Shakers
1
Figure 2
Model: SSM1 & SSM5
Model: SSL1 & SSL2
Sample tray
(220 x 220mm)
Digital control
panel (see fig. 3)
IEC connector
Cradle
System
Digital control
panel (see fig. 3)
IEC
connector
