Studer C221 - Page 176

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
C221
Page: 2 of 2
CONVERTER BOARD 1.747.520.20 ( 3)
R 7 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 8 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 9 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 10 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 11 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 12 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 13 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 14 C057.190479 4R7 5%, 0207, Fuse /!\01 pce
R 15 C057.113105 1M0 MF, 1%, 020701 pce
R 16 C057.113561 560R MF, 1%, 020701 pce
R 17 C057.113471 470R MF, 1%, 020701 pce
R 18 C057.190330 33R 5%, 0207, Fuse /!\01 pce
R 19 C057.190330 33R 5%, 0207, Fuse /!\01 pce
R 20 C057.113103 10k MF, 1%, 020701 pce
R 21 C057.113182 1k8 MF, 1%, 020701 pce
R 22 C057.190330 33R 5%, 0207, Fuse /!\01 pce
R 23 C057.190330 33R 5%, 0207, Fuse /!\01 pce
R 24 C057.113222 2k2 MF, 1%, 020701 pce
R 25 C057.113102 1k0 MF, 1%, 020701 pce
R 26 C057.113222 2k2 MF, 1%, 020701 pce
R 27 C057.113122 1k2 MF, 1%, 020701 pce
R 28 C057.113681 680R MF, 1%, 020701 pce
R 29 C057.113681 680R MF, 1%, 020701 pce
R 30 C057.190220 22R 5%, 0207, Fuse /!\31 pce
R 31 not used00
R 32 not used00
R 33 not used00
R 34 not used00
R 35 C057.113102 1k0 MF, 1%, 020701 pce
R 36 C057.113680 68R MF, 1%, 020701 pce
R 37 C057.113472 4k7 MF, 1%, 020701 pce
R 38 C057.113102 1k0 MF, 1%, 020701 pce
R 39 C057.113222 2k2 MF, 1%, 020701 pce
R 40 C057.113680 68R MF, 1%, 020701 pce
R 41 C057.113562 5k6 MF, 1%, 020701 pce
R 42 C057.113562 5k6 MF, 1%, 020701 pce
R 43 C057.113392 3k9 MF, 1%, 020701 pce
R 44 C057.113102 1k0 MF, 1%, 020701 pce
R 45 C057.113103 10k MF, 1%, 020701 pce
R 46 C057.113103 10k MF, 1%, 020701 pce
R 47 C057.113680 68R MF, 1%, 020701 pce
R 48 C057.113680 68R MF, 1%, 020701 pce
R 49 C057.113680 68R MF, 1%, 020701 pce
R 50 C057.113680 68R MF, 1%, 020701 pce
R 51 C057.113562 5k6 MF, 1%, 020701 pce
R 52 C057.113562 5k6 MF, 1%, 020701 pce
R 53 C057.113562 5k6 MF, 1%, 020701 pce
R 54 C057.113562 5k6 MF, 1%, 020701 pce
R 55 C057.113102 1k0 MF, 1%, 020701 pce
R 56 C057.113474 470k MF, 1%, 020701 pce
R 57 C057.113471 470R MF, 1%, 0207
01 pce
R 58 C057.113471 470R MF, 1%, 020701 pce
R 59 C057.113000 0R0 MF, 020701 pce
R 60 C057.113000 0R0 MF, 020701 pce
R 61 C057.113000 0R0 MF, 020701 pce
R 62 C057.113000 0R0 MF, 020701 pce
R 63 C057.113000 0R0 MF, 020701 pce
R 64 C057.113000 0R0 MF, 020701 pce
R 65 C057.113270 27R MF, 1%, 020701 pce
R 66 C057.113270 27R MF, 1%, 020701 pce
R 67 C057.113121 120R MF, 1%, 020721 pce
R 68 C057.113121 120R MF, 1%, 020721 pce
R 101 C057.113223 22k MF, 1%, 020701 pce
R 102 C057.113243 24k MF, 1%, 020701 pce
R 103 C057.113562 5k6 MF, 1%, 020701 pce
R 104 C057.113752 7k5 MF, 1%, 020701 pce
R 105 C057.113472 4k7 MF, 1%, 020701 pce
R 106 C057.113562 5k6 MF, 1%, 020701 pce
R 107 C057.113103 10k MF, 1%, 020701 pce
R 108 C057.113103 10k MF, 1%, 020701 pce
R 109 C057.113223 22k MF, 1%, 020701 pce
R 110 C057.113243 24k MF, 1%, 020701 pce
R 111 C057.113562 5k6 MF, 1%, 020701 pce
R 112 C057.113752 7k5 MF, 1%, 020701 pce
R 113 C057.113472 4k7 MF, 1%, 020701 pce
R 114 C057.113562 5k6 MF, 1%, 020701 pce
R 115 C057.113103 10k MF, 1%, 020701 pce
R 116 C057.113103 10k MF, 1%, 020701 pce
R 117 C057.113103 10k MF, 1%, 020701 pce
R 118 C057.113101 100R MF, 1%, 020701 pce
R 119 C057.113101 100R MF, 1%, 020701 pce
R 120 C057.113331 330R MF, 1%, 020701 pce
R 121 C057.113331 330R MF, 1%, 020701 pce
R 201 C057.113223 22k MF, 1%, 020701 pce
R 202 C057.113243 24k MF, 1%, 020701 pce
R 203 C057.113562 5k6 MF, 1%, 020701 pce
R 204 C057.113752 7k5 MF, 1%, 020701 pce
R 205 C057.113472 4k7 MF, 1%, 020701 pce
R 206 C057.113562 5k6 MF, 1%, 020701 pce
R 207 C057.113103 10k MF, 1%, 020701 pce
R 208 C057.113103 10k MF, 1%, 020701 pce
R 209 C057.113223 22k MF, 1%, 020701 pce
R 210 C057.113243 24k MF, 1%, 020701 pce
R 211 C057.113562 5k6 MF, 1%, 020701 pce
R 212 C057.113752 7k5 MF, 1%, 020701 pce
R 213 C057.113472 4k7 MF, 1%, 020701 pce
R 214 C057.113562 5k6 MF, 1%, 020701 pce
R 215 C057.113103 10k MF, 1%, 020701 pce
R 216 C057.113103 10k MF, 1%, 020701 pce
R 217 C057.113103 10k MF, 1%, 020701 pce
R 218 C057.113101 100R MF, 1%, 020701 pce
R 219 C057.113101 100R MF, 1%, 020701 pce
R 220 C057.113331 330R MF, 1%, 020701 pce
R 221 C057.113331 330R MF, 1%, 020701 pce
RZ 1 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 2 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 3 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 4 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 5 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 6 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
RZ 7 C057.884103 10k 8*R Resistor-Netw 2% SIP901 pce
S 1 C055.010168 8*a DIL-Switch, PCB01 pce
S 2 C055.010168 8*a DIL-Switch, PCB01 pce
T 1 A769.042004 DOBM-TRANSFORMER01 pce
W 1 C110.011664 WIRE WRAP DRAHT D .255 L=16011 pce
W 2 C110.010964 WIRE WRAP DRAHT D .255 L= 9011 pce
XIC 1 not used00
XIC 2 C053.030164 6p DIL-socket 0.3"01 pce
XIC 3 C053.030164 6p DIL-socket 0.3"01 pce
XIC 4 C053.030166 8p DIL-socket 0.3"01 pce
XIC 5 C053.030166 8p DIL-socket 0.3"01 pce
XIC 6 C053.030166 8p DIL-socket 0.3"01 pce
XIC 7 C053.030173 28p DIL 0.6", löt, gerade01 pce
XIC 8 C053.030172 40p DIL 0.6", löt, gerade01 pce
Y 1 C089.011004 11.059MHz XTAL RW 4301 pce
Y 2 C089.010550 4.0000MHz XTAL HC 18 U01 pce
Y 3 C089.010559 11.289MHz XTAL01 pce
End of List
Comments:
[20] 14.05.91 MOR
(01) 24.06.91 W1,2:added;
(02) 29.10.91 C74:47p->not used;C82...87,MP8,R67,68:added;
(03) 18.05.92 R30:added;
Date printed: 26.10.2010
