Studer C221 - Page 190

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
C221
Page: 1 of 1
LINE AMPLIFIER 1.747.560.00 ( 1)
C 1 C059.226220 22u EL 35V 20% RM501 pce
C 2 C059.225101 100u EL 25V 20% RM501 pce
C 3 C059.225101 100u EL 25V 20% RM501 pce
C 4 C059.344101 100p CER 63V, 5%, N75001 pce
C 5 C059.344101 100p CER 63V, 5%, N75001 pce
C 6 C059.225471 470u EL 35V 20% RM511 pce
C 7 C059.225471 470u EL 35V 20% RM511 pce
C 8 C059.226220 22u EL 35V 20% RM501 pce
C 9 C059.225101 100u EL 25V 20% RM501 pce
C 10 C059.225101 100u EL 25V 20% RM501 pce
C 11 C059.344101 100p CER 63V, 5%, N75001 pce
C 12 C059.344101 100p CER 63V, 5%, N75001 pce
C 13 C059.225471 470u EL 35V 20% RM511 pce
C 14 C059.225471 470u EL 35V 20% RM511 pce
C 15 C059.060104 100n PETP, 63V, 10%, RM501 pce
C 16 not used00
C 17 C059.060104 100n PETP, 63V, 10%, RM501 pce
C 18 C059.060104 100n PETP, 63V, 10%, RM501 pce
C 19 C059.060104 100n PETP, 63V, 10%, RM501 pce
C 20 not used00
D 1 C050.040125 1N4448 75V, 150mA, 4ns, DO-3501 pce
IC 1 C050.090107 4559 Dual Op-Amp01 pce
IC 2 C050.090106 5532A Dual Op-Amp, low noise01 pce
IC 3 C050.090106 5532A Dual Op-Amp, low noise01 pce
IC 4 C050.090107 4559 Dual Op-Amp01 pce
IC 5 C050.090106 5532A Dual Op-Amp, low noise01 pce
IC 6 C050.090106 5532A Dual Op-Amp, low noise01 pce
J 1 C054.212201 3p XLR PCB Winkel01 pce
J 2 C054.212201 3p XLR PCB Winkel01 pce
J 3 C054.010021 Jumper 0.63*0.63mm, Au01 pce
J 4 C054.010021 Jumper 0.63*0.63mm, Au01 pce
J 5 C054.130002 15p D-Sub, PCB, Winkel01 pce
K 1 C056.040196 2*u 12V 125V 2A Ag/Au01 pce
MP 1 A747.056011 LINEAMPLIFIER PCB C 22101 pce
MP 2 A747.056001 NR-ETIKETTE 5 * 2001 pce
MP 3 C020.990103 LIN-FORMSCHR., ZN , D2.2 * 502 pcs
MP 4 C110.011554 15p D-Sub Befestigungs-Bügel01 pce
MP 5 C021.380355 M3*8 Z - Schraube KS A2 blank02 pcs
MP 6 C024.162030 3.2/6.0 Fächerscheibe Form A02 pcs
P 1 C054.010265 8p CIS Stecker-Gehäuse01 pce
P 2 C054.010020 1p Pin, 1reihig, gerade01 pce
P 3 C054.010020 1p Pin, 1reihig, gerade01 pce
Q 1 C050.030436 BC237B NPN 100mA 45V01 pce
Q 2 C050.030436 BC237B NPN 100mA 45V01 pce
R 1 C057.113392 3k9 MF, 1%, 020701 pce
R 2 not used00
R 3 C057.113222 2k2 MF, 1%, 020701 pce
R 4 C057.113682 6k8 MF, 1%, 020701 pce
R 5 C057.113682 6k8 MF, 1%, 020701 pce
R 6 C057.113224 220k MF, 1%, 020701 pce
R 7 C057.113682 6k8 MF, 1%, 020701 pce
R 8 C057.113682 6k8 MF, 1%, 020701 pce
R 9 C057.113224 220k MF, 1%, 020701 pce
R 10 C057.113682 6k8 MF, 1%, 020701 pce
R 11 C057.113682 6k8 MF, 1%, 020701 pce
R 12 C057.113682 6k8 MF, 1%, 020701 pce
R 13 C057.113682 6k8 MF, 1%, 020701 pce
R 14 C057.113682 6k8 MF, 1%, 020701 pce
R 15 C057.113682 6k8 MF, 1%, 020701 pce
R 16 C057.113470 47R MF, 1%, 020701 pce
R 17 C057.113470 47R MF, 1%, 020701 pce
R 18 C057.113470 47R MF, 1%, 020701 pce
R 19 C057.113470 47R MF, 1%, 020701 pce
R 20 C057.113682 6k8 MF, 1%, 020701 pce
R 21 C057.113682 6k8 MF, 1%, 020701 pce
R 22 C057.113682 6k8 MF, 1%, 020701 pce
R 23 C057.113682 6k8 MF, 1%, 020701 pce
R 24 C057.113103 10k MF, 1%, 020701 pce
R 25 C057.113103 10k MF, 1%, 020701 pce
R 26 C057.113392 3k9 MF, 1%, 020701 pce
R 27 not used00
R 28 C057.113222 2k2 MF, 1%, 020701 pce
R 29 C057.113682 6k8 MF, 1%, 020701 pce
R 30 C057.113682 6k8 MF, 1%, 020701 pce
R 31 C057.113224 220k MF, 1%, 020701 pce
R 32 C057.113682 6k8 MF, 1%, 020701 pce
R 33 C057.113682 6k8 MF, 1%, 020701 pce
R 34 C057.113224 220k MF, 1%, 020701 pce
R 35 C057.113682 6k8 MF, 1%, 020701 pce
R 36 C057.113682 6k8 MF, 1%, 020701 pce
R 37 C057.113682 6k8 MF, 1%, 020701 pce
R 38 C057.113682 6k8 MF, 1%, 020701 pce
R 39 C057.113682 6k8 MF, 1%, 020701 pce
R 40 C057.113682 6k8 MF, 1%, 020701 pce
R 41 C057.113470 47R MF, 1%, 020701 pce
R 42 C057.113470 47R MF, 1%, 020701 pce
R 43 C057.113470 47R MF, 1%, 020701 pce
R 44 C057.113470 47R MF, 1%, 020701 pce
R 45 C057.113682 6k8 MF, 1%, 020701 pce
R 46 C057.113682 6k8 MF, 1%, 020701 pce
R 47 C057.113682 6k8 MF, 1%, 020701 pce
R 48 C057.113682 6k8 MF, 1%, 020701 pce
R 49 C057.113103 10k MF, 1%, 020701 pce
R 50 C057.113103 10k MF, 1%, 020701 pce
R 51 C057.113103 10k MF, 1%, 020701 pce
R 52 C057.113103 10k MF, 1%, 020701 pce
R 53 C057.113103 10k MF, 1%, 020701 pce
RA 1 C058.018502 5k0 Cermet, 10%, 0.5W, horizontal01 pce
RA 2 C058.018502 5k0 Cermet, 10%, 0.5W, horizontal01 pce
W 1 A747.056093 LL LINE-AMP01 pce
W 2 A023.031102 FLACHKABEL 16 POL. 0,26M
01 pce
End of List
Comments:
(00) 26.04.91 MOR
(01) 11.12.91 C6,C7,C13,C14:220u->470u;
Date printed: 26.10.2010
