SBM-01 high precision battery monitor
10
or stops charging.
Default : 2.0%
Range : 0.5 – 10.0%
Stepsize : 0.5%
F04 : Charged-parameter-time. This is the time the charged-
parameters (as described in F02 and F03) must be met, in
order to consider the battery as fully charged.
Default : 4 minutes
Range : 1 – 4 minutes
Stepsize : 1 minutes
F05 : Low-battery alarm ON (discharge floor). When the state-of-
charge percentage has fallen below this value, the alarm relay
will be activated and the CHARGE BATTERY indication will
flash on the display to indicate the battery must be charged.
The time-to-go calculation and the state of charge bargraph
are also linked to this value. It is recommended to keep this
value at or around 50.0%.
Default : 50.0%
Range : 0.0 – 99.0%
Stepsize : 1.0%
F06 : Low-battery alarm OFF. When the state-of-charge percentage
has risen above this value and the alarm relay is activated,
the alarm relay will be deactivated again. When FULL is
selected the alarm relay is deactivated when the charged-
parameters are met.
Default : 80.0%
Range : 0.0 – 100.0% / FULL
Stepsize : 1.0%
F07 : Undervoltage alarm. When the battery voltage falls below this
value, after 10 seconds the message Lo shall appear on the
display and the alarm relay will be activated.
Default : 10.5V
Range : OFF / 8.0 – 33.0V
Stepsize : 0.1V
F08 : Overvoltage alarm. When the battery voltage rises above this
value, after 5 seconds the message Hi shall appear on the
