SBM-01 high precision battery monitor
21
Battery capacity range 20 .. 2000Ah
Operating temperature range
0 .. 50°C
Readout resolution :
voltage (0 .. 35V)
± 0.01V
current (0 .. 200A)
± 0.1A
current (200 .. 500A)
± 1A
Amphours (0 .. 200Ah)
± 0.1Ah
Amphours (200 .. 2000Ah)
± 1Ah
state-of-charge (0 .. 100%)
± 0.1%
time-to-go (0 .. 100hrs)
± 1minute
time-to-go (100 .. 240hrs)
± 1hr
temperature (0 .. 50°C) ± 1°C
Voltage measurement accuracy
± 0.3%
Current measurement accuracy
± 0.4%
Dimensions :
frontpanel 65 x 65mm
body diameter
∅ 52mm
total depth 72mm
Equipped with : - Potential free alarm contact
- 500A/50mV current shunt
Accessories : - SBM-01 Connection kit :
- SBM-01 temperature sensor
- SBM-01 RS232 comm.
interface kit
- SBM-01 USB comm. interface
kit
- 1:5 voltage prescaler
Note : the given specifications are subject to change without notice
