Issue 1, October 1997 Model 770 User Guide
Page 40 Studio Technologies, Inc.
Model 770
Referring to the Model 32 or Model 33
schematic diagram, observe the 200 ohm
resistor that is connected between circuit
common and the counterclockwise con-
nection of each potentiometer. This resis-
tor prevents full attenuation. By replacing
this 200 ohm resistor with a 0 ohm
resistor or jumper strap, full attenuation
can be achieved.
