Monitor Output:
Type: electronically balanced, capacitor-coupled,
intended to drive balanced or unbalanced loads
of 600 ohms or greater
Source Impedance: 50 ohms, nominal
Nominal Level: 2dBu, with monitor level control
@ 100%
Maximum Level: +21dBu into 10k ohms,
+20dBu into 600 ohms
Headphone Output:
Compatibility: intended for connection to head-
phones with impedance of 100 ohms or greater
Maximum Voltage: 8Vpp, 100 ohm load
1kHz Tone Output:
Type: electronically balanced, capacitor-coupled,
intended to drive balanced or unbalanced loads
of 600 ohms or greater
Source Impedance: 100 ohms, nominal
Wave Form: sine
Output Level: +4dBu, nominal, adjustable over
1/+3dB
Metering:
Type: analog, VU scale
Calibration: 0 VU = +4dBu, adjustable ±3dB
Illumination: 7 LEDs
Polarity: Input-to-output polarity maintained with
the exception of monitor output, IFB monitor
output, and IFB intercom link output
Specifications subject to change without notice.
