Studiomaster DD 1000 - Specifications

AUDIO INPUTS
MIC-1 Input (¼” Stereo Jack socket) :-
AUDIO OUTPUTS
Effect Out & Direct Out :-
SEND / RETURN (Output / Input)
DIGITAL ECHO PROCESSOR
Output Impedance : <40Ω
Send & Return :
Tip = , Ring = , Shield = Ground
Impedance : Send : <40
¼” Mono Jack socket, Unbalanced 775mV(0dBu)
Ω, Return : >10KΩ
Dual Chip Echo Processor Provide Minimum 136ms to Maximum 790ms Delay
Power Supply : 15V DC (External)
Current Consumption : 250mA max.
Dimensions : Approx. (WXDXH) 145x115x45mm
Weight : 0.7kg
POWER SUPPLY
DIMENSIONS/WEIGHT
Sensitivity : 1.5mVrms Balanced
Input impedance : >5k Ω
Mic-2 Sensitivity : 1.5mVrms (-54dbu) Unbalanced
Mic-2 Input Impedance : >5KΩ
Line I/P Sensitivity : 100mVrms (-17.5) Unbalanced
Line input impedance : >10KΩ
¼” Stereo Jack socket, Unbalanced 775mV(0dBu)
Return Send
(Output) (Input)
Mic-2 / Line Input (¼” Mono Jack socket) :-
SPECIFICATIONS:
