Studiomaster GX10 - Page 8

GX10 GX12 GX15 GX12M GX15M
Power Handling (program) 200W 400W 500W 400W 500W
Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms
Frequency Response 80Hz - 18kHz 60Hz - 18kHz 40Hz - 18kHz 60Hz - 18kHz 40Hz - 18kHz
Sensitivity 1W/1m 97dB 97dB 98dB 97dB 98dB
Crossover frequency 4kHz 4kHz 3kHz 4kHz 3kHz
Low frequency driver 10" 12" 15" 12" 15"
High frequency driver piezo piezo 1.35" driver piezo 1.35" driver
Nominal dispersion (H x V) 90 x 60 degree 90 x 60 degree 90 x 60 degree 90 x 60 degree 90 x 60 degree
Connection (parallel wired) 2 x 4 pole industry standard sockets
Size (w x h x d) metric mm 350 x 520 x 260 390 x 570 x 290 470 x 710 x 350 400 x 530 x 370 680 x 470 x 350
imperial inches 13.8 x 20.5 x 10.2 15.4 x 22.4 x 11.4 18.5 x 28 x 13.8 15.7 x 20.9 x 14.6 26.8 x 18.5 x 13.8
Weight (net) 13kg (28.6lb) 20kg (44lb) 26kg (57.2lb) 20kg (44lb) 26kg (57.2lb)
Weight (shipping) 14.5kg (31.9lb) 21.5kg (47.3lb) 28kg (61.6lb) 21.5kg (47.3lb) 28kg (61.6lb)
