6INSTALLATIONHBASE STÛV16
2
.1 UNPACKING
Step 4 Remove the 4 screws securing the
H base to the pallet.
Step 5 In the complementary box
accompanying the Stûv 16, there is 4
leveling feet These are to be screwed
under the H base
Step 1 Protect the floor with a piece of
cardboard or a protective fabric before
unpacking the Stûv 16 and the H base.
Step 2 Separate the H base pallet from
the Stûv 16 pallet.
Step 3 Dismantle the pallet and check its
contents against the list on page 3. You
will need the Stûv 16 base plate for the
next several steps.
IMPORTANT
The paint is fragile. Be careful not to
scratch the H base with the nails in the
pallet when unpacking.
!
1
2
3
x4
x4
54
321
#2
