5. C0NVECTION
STU
^
V 21 | MODEL SPECIFICATIONS
PAGE 16
The convection air never comes into contact with the fire. The convection is an independant air channel.
The air circulates around the combustion chamber, gets hot and goes out through convection grates in
the same room or in other rooms.
CONVECTION AIR CIRCULATION CONVECTION AIR INLET CONVECTION AIR INLET
HOT AIR OUTLETS
CONVECTION AIR CIRCULATION
