7
3. Recess Mount
Install the cabinet (A) in the wall, using appropriate
mounting screws
(not included)
.
3
A
studs or wooden framing
1. Recess Mount
Hold the cabinet (A) at the desired position on wall.
NOTE: Make sure the cabinet is level.
Trace the outline of the cabinet (A) on the wall.
NOTE: The cabinet should be positioned between
two studs. If the cabinet will not be positioned between
two studs, a frame of wood must be constructed in the
wall surrounding the outline of the location of
the cabinet.
1
2. Recess Mount
Cut a hole in the wall along the traced line.
2
cut out the outline
of the cabinet
A
outline of the cabinet
INSTALLATION INSTRUCTIONS
IS2331
