Planning Information
Undercounter Model 249RP
Dimensions in parentheses are in
millimeters unless otherwise specified.
4
INSTALLATION NOTES
R
efer to the illustrations and specifications
for overall dimensions, finished rough opening
dimensions and installation specifics.
A
115 V AC, 60 Hz, 15 amp fused electrical
supply is required. It is recommended that a
separate circuit, serving only this appliance, be
provided.
All Undercounter models are equipped with a
power supply cord with a 3-prong grounding
plug which must be plugged into a mating
3-prong grounding type wall receptacle. Locate
electrical within the shaded area shown in the
illustration on page 3.
Y
ou must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
R
efer to the Undercounter Installation
Instructions packed with the appliance, which
provides step-by-step procedures for making
sure the unit is installed properly.
