Planning Information
Undercounter Model 315 l(P)
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
DOOR PANEL
It is important to understand the differences in mounting
any wood panel to Model 315I(P). The panel must be
5
/8"
(16) minimum thickness. Refer to the installation instruc-
tions packaged with the unit to understand how the panel
is installed. It does not require a
1
/4" (6) backer. No handle
recess is required.
Refer to the following chart for door panel dimensions for
the Model 315I(P).
DOOR
PANEL DIMENSIONS
Door Panel Width 15" (381)
Door Panel Height 30
3
/8" (772)
Door Panel Thickness
5
/8" (16) min
Maximum Panel Weight 15 lbs (7 kg)
Door Panel Dimensions
