Sub-Zero 601R-2 User Manual

Built-In
Built-In
(600-
(600-
2
2
)
)
Series
Series
Sealed System Information
4-7
#3758407 - Revision B - August, 2006
Figure 4-9. Models 611-2, 611G-2, 650-2, 650G-2 Refrigerant Flow
Figure 4-10. Models 632-2, 642-2, 661-2, 685-2, 695-2 Refrigerant Flow
Freezer Compressor
Freezer Drier
Freezer Heat Exchanger
Drain Pan Heater
Freezer Heater Loop
Freezer Evaporator
Refrigerator Evaporator
Refrigerator Heater Loop
Refrigerator Heat Exchanger
Refrigerator Drier
Refrigerator Compressor
Dual Condenser
Drain Pan Heater
Freezer Heat Exchanger
Freezer Compressor
Freezer Heater Loop
Freezer Evaporator
Freezer Drier
Refrigerator
Drier
Refrigerator Heater Loop
Refrigerator
Evaporator
Dual Condenser
Refrigerator Compressor
Refrigerator
Heat Exchanger
