14
|
Sub-Zero Customer Care 800.222.7820
BUILT-IN REFRIGERATION
Opening Dimensions
STANDARD INSTALLATION
83
3
/4"
(2127)
OPENING
HEIGHT
24" (610)
OPENING
DEPTH
NOTE: Shaded line represents profile of unit.
FRONT VIEW
VIEW
TOP VIEW
W
OPENING WIDTH
OPENING WIDTH
W
30" Model 29
1
/2" (749)
36" Model 35
1
/2" (902)
42" Model 41
1
/2" (1054)
48" Model 47
1
/2" (1206)
If an 83" (2108) grille height is specied, the opening height
must be decreased by
7
/8" (22). If an 88" (2235) grille height is
specied, the opening height must be increased by 4"
(102).
If two units are installed side by side, refer to page 16 for
dual standard installations.
UNDERCOUNTER WINE INTEGRATED PRO 48 BUILT-IN
