INSTALLATION NOTES
Built-In models may be used in a standard
installation or in a flush inset installation
which allows the unit to be flush with
surrounding cabinetry.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com/specs.
SPECIFICATIONS
Overall Dimensions 36"W x 84"H x 24"D
Door Clearance Standard 37
1
/4"
Flush Inset 37
3
/4"
Opening Width 35
1
/2"
Flush Inset Width 38"
Opening Height 83
3
/4"
Flush Inset Height 84"
Opening Depth 24"
Flush Inset Depth 26
3
/16"
Electrical Requirements 115 V AC, 60 Hz
15 amp circuit
Shipping Weight 420 lbs
36" Built-In All Refrigerator
OVERALL DIMENSIONS
©Sub-Zero, Inc. all rights reserved. Features and specifications are subject to change at any time without notice. 7/11
36" (914)
84"
(2134)
24" (610)
4
"
(102)
7
3
3
/4"
(1873)
23
7
/8"
(606)
37
1
/4"
(946)
1
7"
(432)
23
7
/8" (606)
2
3
/8" (60)
HEIGHT DIMENSIONS ±
1
/2" (13)
U
nit dimensions
may vary by
±1/8" (3).
Dimensions in
parentheses are
i
n millimeters
unless otherwise
s
pecified.
24" (610)
OPENING
DEPTH
FRONT VIEWSIDE VIEW
TOP VIEW
35
1
/2" (902)
OPENING WIDTH
24" (610)
OPENING DEPTH
83
3
/4"
(2127)
OPENING
HEIGHT
Flush Inset Installation
INSTALLATION SPECIFICATIONS
S
tandard Installation
IMPORTANT NOTE:
Dimensions assume
a
3
/4" (19) panel
thickness.
UNIT WITH
3
/4" (19) P
ANEL
DETAIL A
DETAIL B
FRONT VIEW
35
1
/2" (902)
WIDTH TO CLEAT
38" (965)
FLUSH INSET WIDTH
1
1
/4"
(32)
1
1
/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
24" (610)
DEPTH TO CLEAT
26
3
/16" (665)
FLUSH INSET DEPTH
2
3
/16"
(56)
83
3
/4"
(2127)
HEIGHT
TO CLEAT
24" (610)
DEPTH
TO CLEAT
26
3
/16"
(665)
F
LUSH
INSET
DEPTH
TOP VIEW
2
3
/16"
(56)
1
1
/4"
(32)
C
LEAT
CLEAT
Detail A
Detail B
1
1
/4"
(32)
24" (610)
OPENING
DEPTH
TO CLEAT
CLEAT
TOP VIEW
26
3
/16"
(665)
FLUSH
INSET
DEPTH
2
3
/16" (56)
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
1
1
/4"
(32)
2
3
/16" (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (102)
3
L
ocation of
E
lectrical Supply
F
RONT VIEW
75
1
/2"
(1918)
FROM
FLOOR
7"
(178)
E
6
"
(152)
