Sub-Zero ICB700 T Series User Manual

8-4
Troubleshooting Guides
7005836 - Revision A - January, 2009
International Integrated
International Integrated
(ICB700 T
(ICB700 T
all)
all)
Series
Series
ERROR CODE TEST / ACTION
30
40
50
A. Check for jammed cube in icemaker.
B. Reference wiring diagram to identify components in same White wire circuit as water valve solenoid.
Check all White wire electrical connections and continuity from water valve solenoid to J7-8 on control
board.
A. If Error Code 07, 20, 21, 22, 23, or 24 is also displayed during Diagnostic Mode, see Test/Actions
under that code.
B. Check for obstructions to freezer door/drawer closing. Remove obstruction.
C. Check cleanliness of condenser. Clean if needed.
D. Check for obstruction to condenser fan blade or loose fan blade. Remove obstruction/Tighten Blade.
E. Check evaporator fan blade position and for obstructions. Reposition if incorrect/Remove obstruction.
F. Check resistance of freezer compartment thermistor - 30,000 to 33,000 ohms at 0°C (32°F). Replace
if defective.
G. With unit on, check to see if lights shut off when light switch is depressed. Repair defective wiring or
replace defective switch.
H. With freezer compressor running:
1. (Model ICB700TF/I Only) Check for 230 V AC from compressor to condenser fan. Repair defec-
tive wiring or replace defective motor.
2. (All Models Except ICB700TF/I) Check for 230 V AC from control board to condenser fan. Repair
defective wiring, or replace defective motor, or replace defective board.
I. With freezer compressor running and fan switches depressed, check for 230 V AC from compressor
to evaporator fan motor. Repair wiring, or replace defective switch, or replace defective fan motor.
J. Check sealed system for leaks, restrictions or inefficient compressor.
A. If Error Code 05, or 06 is also displayed during Diagnostic Mode, see Test/Actions under that code.
B. Check for obstructions to refrigerator door closing. Remove obstruction.
C. Check cleanliness of condenser. Clean if needed.
D. Check for obstruction to condenser fan blade or loose fan blade. Remove obstruction/Tighten Blade.
E. Check evaporator fan blade position and for obstructions. Reposition if incorrect/Remove obstruction.
F. Check resistance of refrigerator compartment thermistor - 30,000 to 33,000 ohms at 0°C (32°F).
Replace if defective.
G. With unit on, check to see if lights shut off when light switch is depressed. Repair defective wiring or
replace defective switch.
H. With refrigerator compressor running (All models except ICB700TF/I) check for 230 V AC from control
board to condenser fan. Repair defective wiring, or replace defective motor, or replace defective
board.
I. With refrigerator compressor running and fan switches depressed (All Models Except ICB700TF/I),
check for 230 V AC from compressor to evaporator fan motor. Repair wiring, or replace defective
switch, or replace defective fan motor.
J. Check sealed system for leaks, restrictions or inefficient compressor.
ERROR CODE TROUBLESHOOTING GUIDE
NOTE: After repairs, always clear Error Codes by pressing Bell ON/OFF key for 15 seconds.
