BUILT-IN REFRIGERATION
Plumbing
For built-in models with an automatic ice maker, the water
supply line should be located within the shaded area shown
in the illustration below. The water supply line should be
connected to the house supply with an easily accessible
shut-off valve. Do not use self-piercing valves. The water
supply line must not interfere with installation of the anti-tip
brackets.
A reverse osmosis system can be used provided there
is constant water pressure of 2.4–8.3 bar supplied to the
unit at all times. A copper line is not recommended for this
application.
Installation must comply with all applicable plumbing codes.
PLUMBING REQUIREMENTS
Water Supply Line 6.35 mm OD copper line,
braided stainless steel, or PEX tubing
Water Pressure 2.4–8.3 bar
Excess Water Line for Connection .9 m
Electrical
International models from the factory designed without a
transformer require a 220-240 V AC, 50/60 Hz electrical
supply, fused at the correct rating for the unit. If required
by local or national codes, the power cord can be easily
replaced using the power inlet device.
The electrical supply should be located within the shaded
area shown in the illustration below. A separate circuit, ser-
vicing only this appliance is required. A ground fault circuit
interrupter (GFCI) is not recommended and may cause inter-
ruption of operation.
Installation must comply with all applicable electrical codes.
ELECTRICAL REQUIREMENTS
Power Supply 220-240 V AC, 50/60 Hz
Circuit Breaker 10 amp
Receptacle grounding-type (earthed)
1918 mm
FROM FLOOR
178
mm
E
152
mm
RIGHT SIDE
OF OPENING
Electrical supply location.
76 mm
457 mm
152
mm
RIGHT SIDE
OF OPENING
AREA EXTENDS 13 mm
FORWARD ON FLOOR
Water supply location.
WINE INTEGRATED PRO 48 BUILT-IN
