WINE STORAGE
Custom Panels—ICBWS-30
FLUSH INSET PANELS
The ush inset application is an overlay model with ush
inset panels. It is not a separate model.
The ush inset design allows custom panels to be installed
ush with adjacent cabinets. Similar to overlay, ush inset
panels are typically created by combining a 19 mm custom
panel, a 3 mm spacer panel and a 6 mm backer panel. Refer
to the illustrations for overlay panels on the previous page.
For ush inset panels thicker than 19 mm, a 90° door stop
may be required to prevent interference with adjacent cabi-
nets. Refer to the full-scale template on page 68.
PANEL REQUIREMENTS
PANEL WEIGHT MAX
Door 34 kg
Grille 6 kg
PANEL THICKNESS MIN
Flush Inset 16 mm
FLUSH INSET PANEL DIMENSIONS
H
H
W
A
A
ICBWS-30
FLUSH INSET PANELS
DOOR W H
Flush Inset Panel 787 mm 1772 mm
Spacer Panel 740 mm 1751 mm
Backer Panel 756 mm 1767 mm
STILES / RAILS A
Minimum 95 mm
GRILLE W H
Flush Inset Panel 787 mm 235 mm
Spacer Panel 740 mm 211 mm
Backer Panel 756 mm 227 mm
Grille panel dimensions are for standard 2134 mm overall unit
height. For 2108 mm height, subtract 25 mm from grille panel
height dimensions and for 2235 mm height, add 102 mm. A specic
panel grille must be ordered for a 2108 mm or 2235 mm overall unit
height.
