Sub-Zero IT30RRH User Manual

8 | Sub-Zero Customer Care 800.222.7820
STORAGE
Freezer Storage
FREEZER BASKETS
To remove, pull forward until basket stops. Pull the two
plastic tabs located behind the bottom two corners of the
basket forward, then lift up and out. Refer to the illustration
below. To reinstall, push drawer slides in. Align the basket
with slides and push back until it stops. Press down on the
front of the basket to engage slides. Refer to the illustration
below.
If door opening is limited to 90°, the top basket must be
removed before removing the middle or lower basket.
ICE CONTAINER
Column | To remove ice container, pull freezer drawer open
until it stops and lift container out. To reinstall, pull drawer
carrier out and align the bottom of the container with the
carrier. Refer to the illustration below.
Tall and drawer | To remove ice container, pull freezer
drawer open until it stops and lift container out. To reinstall,
place in the drawer with tabs on the bottom of the container
aligned with slots in the drawer. Refer to the illustration
below.
The ice maker must be turned off by touching
when
the ice storage container is removed. The unit is equipped
with a 3-minute delay after the ice container is removed, to
ensure cubes are not ejected before ice maker can be deac-
tivated or ice container is reinstalled.
Freezer basket removal.
Column ice container. Tall and drawer ice container.

Sub-Zero IT30RRH Specifications

General

Type	built-in
Style	no freezer
Color	custom, custom panel ready
Number of Doors	3
Total Capacity	16.5 cubic feet
Refrigerator Capacity	16.5 cubic feet
Defrost System	automatic
Number of Refrigerator Shelves	3
Temperature Control	electronic
Interior Light	led
Dispenser	none
Ice Maker	no
Water Filter	no
Air Filter	yes
Door Alarm	yes
Smart Home	yes
Wi-Fi	wi-fi
Annual Energy Consumption	324 kilowatt hours
Voltage	115 volts
Current	15 amperes

Weight and Dimensions

Depth	24 inches
Height	84 inches
Width	30 inches
Net Weight	400 pounds
