• In Program Mode
Press and hold “ ” key for 2 Sec. Display will flash “CS” parameter if “PA” value
is kept “0”. If other than “0”, then “PA” and “0” will flash. Use “ ” and “ ” keys
to enter the password. On entering correct value, display will flash the first
parameter “CS”. User can scroll through parameters using “ ” or “ ” keys.
To save the modified value use “SET” key.
• In Set Mode
Press and hold “SET” key for 2 Sec. Display will flash SP1/SP2 (depends on CS
parameter)” parameter if “PA” value is kept to “0”. If other than “0”, then display
will flash “PA” and “0”. Use “ ” and “ ” to enter the password. On entering
correct value, display will flash “SP1/SP2 (depends on CS parameter)” parameter.
User can set desired value using “ ” or “ ” keys. To save the modified value
use “SET” key.
• Press UP+DOWN key simultaneously for 2 Seconds. Controller will enter
into Run hour and Fault Log Mode, select FLG parameter.
• If there are no Fault records, Display will show "noF".
• If Faults are present the latest Fault will be displayed first, Fault message
will be flashed with Fault Number at the rate of 500ms.
Note: For the Fault messages refer the table “Fault Messages”. Scroll through the
faults using UP/DOWN keys.
