Sub-Zero UC-15I Installation & Operation

5
S U B - Z E R O I C E M A C H I N E I N S T A L L AT I O N
O V E R A L L D I M E N S I O N S
Models UC-15I, UC-15IP, UC-15IO & UC-15IPO
33
5
/8"
(854)
33
5
/8"
(854)
14
3
/4"
(375)
29
5
/8"
(752)
4"(
102)
21
5
/1
6
"
(541)
1
1
1
/16"*(43)
21
5
/1
6
"
(541)
TOP VIEW
14
3
/4"
(
375)
115˚
D
OOR SWING
SIDE VIEWFRONT VIEW
*
Does not include door panel
6
1
/2"
(165)
18"
(
457)
A L L M O D E L S
Overall Width 14
3
/4" (375)
O
verall Height (levelers in) 33
5
/8"
(854)
Overall Depth 23" (584)
Minimum Door Clearance 18" (457)
Rough Opening Width 15
1
/4" (387)
Rough Opening Height 34
1
/2" (876)
Minimum Height Required
(levelers in) 33
5
/8" (854)
Rough Opening Depth 24" (610)
Dimensions may vary ±
1
/8" (3).
24" (610)
ROUGH
OPENING
DEPTH
LOCATION OF
WATER LINE
8"
(203)
1
/2"
(
13
)
TOP VIEW
34
1
/2" (876)
ROUGH
OPENING
HEIGHT
33
5
/8" (854)
MINIMUM
HEIGHT
REQUIRED
15
1
/4"min (387)
ROUGH
OPENING WIDTH
POSITION OUTLET
WITH GROUNDING
PRONG ON RIGHT
FRONT VIEW
4"
(
102
)
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
I N S T A L L AT I O N S P E C I F I C AT I O N S

Sub-Zero UC-15I Specifications

General

Brand	Sub-Zero
Model	UC-15I
Category	Ice Maker
Language	English
