Sub-Zero UC-15I

INSTALLATION NOTES
The electrical supply can be located anywhere
on the back wall.
The ice machine can be ordered with (models
UC-15IP and UC-15IPO) or without (models
UC-15I and UC-15IO) a drain pump. Each
model has specific plumbing requirements.
If you order the unit without a pump, a drain
must be installed.
Complete installation specifications, including
panel dimensions, can be found on our
website, subzero.com/specs.
SPECIFICATIONS
Overall Width 14
3
/4"
Overall Height (levelers in) 33
5
/8"
Overall Depth 23"
Minimum Door Clearance 18"
Ice Storage Capacity 26 lbs
Opening Width 15
1
/4"
Opening Height 34
1
/2"
Opening Depth 24"
Minimum Height Required
(levelers in) 33
5
/8"
Electrical Requirements 115 V AC, 60 Hz
15 amp dedicated circuit
Plumbing Requirements
1
/4" copper line
20–100 psi
Shipping Weight 117 lbs
15" Undercounter
Ice Machine
15
1
/4"min
(387)
OPENING WIDTH
TOP VIEW
TOP VIEW
FRONT VIEW
1
/8" (
3)
DRAIN
TUBE
WATER
INLET TUBE
SHUT-OFF
VALVE
DRAIN
TUBE
WATER
INLET
TUBE
SHUT-OFF
VALVE
DRAIN
15
1
/4"min
(387)
OPENING WIDTH
TOP VIEW
TOP VIEW
FRONT VIEW
1
/8" (
3)
DRAIN TUBE
SHUT-OFF
VALVE
AIR GAP
DEVICE
DRAIN TUBE
AIR GAP
DEVICE
WATER
INLET TUBE
SHUT-OFF
VALVE
WATER
INLET TUBE
Gravity Drain Models
Drain Pump Models
©Sub-Zero, Inc. all rights reserved. Features and specifications are subject to change at any time without notice. 6/10
Unit dimensions may vary by ±
1
/8".
O
verall dimensions do not include panels or handles.
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
Dimensions in parentheses are in
millimeters unless otherwise specified.
14
3
/4" (375) 23" (584)
33
5
/8"
(854)
4" (102)
18"
(457)
Location of Water Supply
LOCATION OF
WATER LINE
8"
(203)
1
/2"
(
13
)
TOP VIEW
