5-4
Audio
!
Type B audio set
"
Radio operation: refer to page 5-19
"
Built-in CD ch
anger operation: refer
to page 5-24
!
Type C audio set
"
Radio operation: refer to
page 5-38
"
Built-in CD changer operation: refer to page
5-43
PUSH POWER-VOL
SEEK
SCAN
TUNE
TRACK
AUDIO
6 CD CHANGER P-201UH
BAL
RPT
RDM
LOAD
FM
AM
CD
123
4
5
6
UB5201AA
PUSH POWER-VOL
SEEK
SCAN
FOLDER
TUNE
TRACK
AUDIO
MP3
6 CD CHANGER P-201UE
BAL
RPT
RDM
TEXT
LOAD
FM
AM
CD
123
4
5
6
UB5202AA
258
260
